Stone Cutting Machine – AD260

This Stone Cutting Machine AD-260 is designed for precise cutting of various stones, ceramics, and façade bricks up to 10 cm thick. It supports 90° straight cuts, 45° mitre cuts, chamfering, grooving, and can be fitted with different cutting discs.

The machine features a water tank with a circulation pump for ease of use and reduced weight. Its adjustable screw legs allow leveling on uneven surfaces. Cutting discs from 250 mm to 350 mm are standard, with 400 mm discs available on request. This model offers larger wagon bearings, a sturdier chassis, wider guide rods, and a manual gearbox for enhanced durability and performance.

Technical Details

Useful Cutting Length 260 cm
Total Machine Length 300 cm
Work Table Width 65 cm
Auxiliary Table Dimensions 30 x 60 cm
Maximum Cutting Diameter 10 cm
Installable Cutting Disc Dimensions 25 – 35 cm (40 cm on customer request)
Motor Power 2200 W (3 HP)
Motor Rotation Speed 3000 RPM
Work Table Material Premium Galvanized Steel
Machine Weight 260 kg
Power Consumption 13 A
